Hybrid Inverter ESS Energy Storage System High Voltage VP Batteries 512V All In One Cabinet 10*16S1P

Hybrid Inverter ESS Energy Storage System High Voltage VP Batteries 512V All In One Cabinet 10*16S1P

ess energy storage system high voltage

512v ess battery

512v ess energy storage system

Place of Origin:

China

Brand Name:

VP / No Logo / Customize brand / OEM / ODM

Certification:

MSDS CE UN38.3 ROHS EMC IEC

Model Number:

VP50-VP-104

Chat Now
Request A Quote
Hybrid Inverter ESS Energy Storage System High Voltage VP Batteries 512V All In One Cabinet 10*16S1P Hybrid Inverter ESS Energy Storage System High Voltage VP Batteries 512V All In One Cabinet 10*16S1P Hybrid Inverter ESS Energy Storage System High Voltage VP Batteries 512V All In One Cabinet 10*16S1P
Product Details
Product Name:
Plug And Play Modular Stackable Battery ESS
Battery Chemistry:
Lithium-ion
Assemble:
10*16S1P
Voltage:
512V
Temperature Control:
Forced Air Cooling
Fire Protection System:
AEROSOL Fire Extinguishing
Monitoring:
BMS
Whole Equipment Size:
860 * 760* 2077mm
Highlight:

ess energy storage system high voltage

,

512v ess battery

,

512v ess energy storage system

Payment & Shipping Terms
Minimum Order Quantity
1 pieces
Price
Reconsideration
Packaging Details
Standard Wooden Box
Payment Terms
L/C,D/P,T/T,Western Union,MoneyGram
RELATED PRODUCTS
Good price Air Cooling ESS Integrated Energy Storage System VP 145.08KWH Battery Pack Cabinet online

Air Cooling ESS Integrated Energy Storage System VP 145.08KWH Battery Pack Cabinet

Chat Now
Good price Lithium Ion 104AH 26.64KWH ESS Energy Storage System Container VP Solar Power Batteries online Video

Lithium Ion 104AH 26.64KWH ESS Energy Storage System Container VP Solar Power Batteries

Chat Now
Good price 1P160S VP Solar Energy Storage System 106KWH Outdoor Cabinet ESS Batteries online Video

1P160S VP Solar Energy Storage System 106KWH Outdoor Cabinet ESS Batteries

Chat Now
Good price 215KWH Containerized VP Battery Energy Storage System 100KW PCS ESS Solar Batteries online

215KWH Containerized VP Battery Energy Storage System 100KW PCS ESS Solar Batteries

Chat Now
CONTACT US
86--15692497946
vppowerbattery@vppowerbattery.com
Chat Now
Product Description
Hybrid Inverter ESS High Voltage 512V Energy Storage System All In One Cabinet
Product Attributes
Attribute Value
Product Name Plug And Play Modular Stackable Battery ESS
Battery Chemistry Lithium-ion
Assemble 10*16S1P
Voltage 512V
Temperature Control Forced Air Cooling
Fire Protection System AEROSOL Fire Extinguishing
Monitoring BMS
Whole Equipment Size 860 * 760* 2077mm
Guangzhou Victory Technology Co., Ltd. Emerging energy technology enterprise rooted in China, specializing in the R&D and manufacturing of high-reliability dry cell batteries, lithium batteries, and energy storage system solutions.
Hybrid Inverter ESS Energy Storage System High Voltage VP Batteries 512V All In One Cabinet 10*16S1P 0
  • We have a 5000 square meter production base, a mature production team, and 20+ high-precision battery production lines.
  • We provide OEM customization services and have become the trusted choice of many customers.
  • The battery has passed formal quality certification and obtained various certificates such as lSO9001, SGS and CE for explosion and leakage prevention.
  • Having an experienced professional production team and technical personnel.

Hybrid Inverter ESS Energy Storage System High Voltage VP Batteries 512V All In One Cabinet 10*16S1P 1

Hybrid Inverter ESS Energy Storage System High Voltage VP Batteries 512V All In One Cabinet 10*16S1P 2

Product Description
Hybrid Inverter ESS High Voltage 512V Energy Storage System All In One Cabinet
Quick Detail:
  • All In One Integration
  • Intelligent Scheduling
  • Rapid Maintenance
  • Aerosol Firefighting
  • Optional Communication (RS485 & CAN)
Specifications:
Product Performance VP25-VP-104 VP50-VP-104
Rated load 26.64KWH 53.2KWH
Configuration 5*1P16S 10*16S1P
Rated Voltage 256V 512V
Rated Capacity 104AH 104AH
Operating Voltage Range 216-292V 432-584V
Rated Charge and Discharge Current 100A 100A
Rated Charge and Discharge Power 26KW 51KW
Net Weight 364KG±3KG 650KG±6KG
Size 860*760*1248mm 860*760*2077mm
Gross Weight 419KG±4KG 723KG±7KG
Communication CAN/RS485 CAN/RS485
Storage Temperature -10~30℃ -10~30℃
Charging Temperature 0~40℃ 0~40℃
Discharge Temperature -20~40℃ -20~40℃
Waterproof Grade IP20 IP20
All-in-one industrial energy storage cabinet combines advanced forced air cooling with certified aerosol fire suppression for plug-and-play deployment, reducing installation time through modular stackable design. With intelligent BMS monitoring and EMS integration, the system provides dynamic load balancing, real-time anomaly detection, and predictive maintenance to reduce operational costs. Optimized for C&I solar ROI, the system features scalable capacity expansion and peak shaving functionality while maintaining operational safety via multi-layer protection systems.

Hybrid Inverter ESS Energy Storage System High Voltage VP Batteries 512V All In One Cabinet 10*16S1P 3

Hybrid Inverter ESS Energy Storage System High Voltage VP Batteries 512V All In One Cabinet 10*16S1P 4

Notices:
  1. Installation/maintenance by certified electricians complying with local grid codes.
  2. Absolute ban on wet environment operation (IP20 minimum).
  3. First disconnect the circuit breaker on the grid side, then disconnect the DC switch on the battery side.
  4. Charge to SOC≥30% every 3 months during long-term storage.
  5. No heating/incineration of the battery.
Applications:
Target applications include optimize C&I demand charges, stabilize renewable integration, and ensure backup power for factories, microgrids, and EV hubs.
Hybrid Inverter ESS Energy Storage System High Voltage VP Batteries 512V All In One Cabinet 10*16S1P 5
FAQ
Q1: Who are we?
A1: Guangzhou Victory Technology Co., Ltd., headquartered in Guangzhou, China, with 12 international production bases and an annual output of 40 billion units, provides reliable energy storage solutions globally.
Q2: How do we ensure quality?
A2: Our products meet global safety and quality standards, certified by KC, CB, CE, PSE, FCC, RoHS, and UN38.3, ensuring top-tier reliability and customer satisfaction worldwide.
Q3: Is it OK to print my logo on the product?
A3: Yes. Please inform us formally before our production.
Q4: What is the minimum order of products?
A4: Different products have different MOQ, but we can provide samples for you to test.
Q5: Can we visit your factory?
A5: Warmly welcome. Once we have your schedule, we will arrange the professional sales team to follow up your case.
If you have any other questions, please feel free to contact us. Welcome your inquiry.
