Place of Origin:
China
Brand Name:
VP / No Logo / Customize brand / OEM / ODM
Certification:
MSDS CE UN38.3 ROHS TUV IEC
Model Number:
1.1MWH
| Battery Data | |
| Battery Protection Value | 2.7V~3.6V |
| Battery Cycle Efficiency | ≥90%@AC |
| Battery Cell Combination | 1P220S |
| Nominal Capacity | 1.1MWH |
| Rated Power | 500KW |
| Voltage Range | 594V~792V |
| Matching PCS | 500KW |
| General Parameter | |
| Dimensions(W*H*D) | 2991*2438*2896MM |
| Weight | 15T |
| Protection Grade | IP54 |
| Voltage Range | 500KW |
| Humidity Range | 0-95%RH (No Condensation) |
| Fire Protection Standard / Optional | Aerosol |
| Operating Temperature | -20~50℃ |
1. All operations must be performed by certified professional technicians following local electrical codes.
2. Verify correct polarity connections before energizing the system.
3. Conduct initial inspection for physical damage or abnormal conditions.
4. Keep all power switches in OFF position during installation.
5. Maintain operating environment within 5-95% relative humidity range.
Q:Do you support OEM / ODM?
A:Of course, we can do customized services for our partners.
Q:Who are we?
A:Guangzhou Victory Technology Co., Ltd., headquartered in Guangzhou, China, with 12 international production bases and an annual output of 40 billion units, provides reliable energy storage solutions globally.
Q:Why should you buy from us instead of other suppliers?
A:We supply reliable energy storage solutions globally, with advanced technologies and efficient delivery capabilities. we export to key markets in Europe, Americas, Japan, Korea, and Southeast Asia.
Q:Can we visit your factory?
A:Warmly welcome. Once we have your schedule, we will arrange the professional sales team to follow up your case.
Q: How long does it take to ship after an order is completed?
A: The shipping time depends on the scale of the order and specific requirements. We provide an estimated shipping time after the order is confirmed.
