Place of Origin:
China
Brand Name:
VP / No Logo / Customize brand / OEM / ODM
Certification:
MSDS CE UN38.3 ROHS TUV IEC
Model Number:
145.08KWH
| Battery Data | |
| Rated load | 145.08KWH |
| Rated Capacity | 280AH |
| Rated Power | 50KW |
| Input/Output Voltage | 3L/N/PE230/400VA.C |
| Input/Output Frequency | 50/60HZ |
| Voltage Range | 405-591.3V |
| Nominal Voltage | 518.4V |
| General Parameter | |
| Dimensions(W*H*D) | 1950*1000*1845mm |
| Weight | 2200KG |
| Protection Grade | IP54 |
| Humidity Range | ≤95% (Not-Condensing) |
| Temperature | -20~45℃ |
| Communication | CAN/RS485 |
| Battery Temperature Control Method | Air Cooling |
| Fire Protection System | Aerosol |
Guangzhou Victory Technology Co., Ltd. is a trusted manufacturer and partner for integrated power solutions—from dry and lithium-ion batteries to energy storage systems ( ESS ). Our focus on innovation and reliability ensures that our systems are engineered to optimize the efficiency, stability, and sustainability of your operations.
1. Regular inspection for physical damage and unusual odors required.
2. No unauthorized parameter modifications permitted.
3. Strictly prohibit reverse polarity connections
4. Disengage all circuit breakers during long-term storage.
5. Battery compartment access limited to authorized technicians.
Optimizing energy utilization across sectors, vp energy storage systems enable self-consumption for manufacturing plants, peak shaving in commercial complexes, UPS functionality for data centers, backup power for industrial parks, ESS for facility management, and HESS for grid services, supporting diverse energy strategies.
Q:Could you do customer brand?
A:Of course ,we could provide professional OEM service.
Q:How do we ensure quality?
A:Our products meet global safety and quality standards, certified by KC, CB, CE, PSE, FCC, RoHS, and UN38.3, ensuring top-tier reliability and customer satisfaction worldwide.
Q:Is this product safe?
A:Anti-short circuit, anti-scalding, explosion-proof, and environmentally friendly.
Q:What can I buy from here?
A:We specialize in products for industries, offering a range of dry batteries, lithium-ion batteries, home energy storage systems, commercial & industrial energy storage systems and emergency start equipment.
Q:Can the BMS be removed and replaced if it breaks? Can the case be opened to replace a bad cell?
A:Yes, the case can be opened to replace the BMS & cells on the guidance of engineer.
