Place of Origin:
China
Brand Name:
VP / No Logo / Customize brand / OEM / ODM
Certification:
MSDS CE IEC UN38.3 ROHS TUV
Model Number:
VP-AC-S2
10.24KWH High Voltage VP LiFePO4 System Split Stackable Energy Storage Battery
Key Features & Benefits for Your Business:
Specifications:
| Product Performance | VP-AC-S2 |
|---|---|
| Rated Capacity | 10.24KWH |
| Cell Type | Lithium Iron Phosphate |
| Cell Configuration | 2*32S1P |
| Rated Voltage | 204.8V |
| Rated Capacity | 50AH |
| Operating Voltage Range | 172.8V~233.6V |
| Rated Charge And Discharge Current | 50A |
| Rated Charge And Discharge Power | 10.24KW |
| Communication | CAN / RS485 |
| Cycle Life | 6000 |
| Operating Temperature Range | -15~45℃ |
| Relative Humidity | 5%~65% |
| Weight | 121±4KG |
| Size(L*W*H) | 630*380*720mm |
| Battery Box Packaging Weight | 64KG |
| Main Control Box Packaging Weight | 24.3KG |
Guangzhou Victory Technology delivers custom energy storage systems built to your specifications. We oversee core manufacturing processes to maintain strict quality control and cost-effective production. Whether you need lithium batteries, dry cell batteries, or complete system solutions, our OEM/ODM services ensure products meet your expectations. Backed by local after-sales engineers and direct business support, we provide a reliable partnership for your clean energy projects.
Description:
Designed for over 10 years of service, it combines space efficiency with long-term reliability in one streamlined unit. Its construction uses high-performance Lithium Iron Phosphate (LiFePO4) cathode material for excellent cell consistency and safety. The 10.24KWH 204.8V Home Energy Storage System features a highly integrated modular design, saving valuable installation space. This architecture allows for a compact footprint while delivering substantial capacity.
Applications:
A reliable partner for small factories and charging stations. This system provides stable backup power and enables cost savings through peak-valley energy shifting. It ensures operational continuity and manages energy consumption efficiently for small-scale commercial needs.
Notices:
1. Before installation, verify that the battery voltage and inverter power rating are correctly matched to your photovoltaic system specifications.
2. Battery replacement must only be performed by the original cell supplier or authorized device supplier. Do not attempt this yourself.
3. Use flame-retardant cables with clear polarity markings. Ensure all screws are tight and communication lines are secure. Proper grounding is mandatory for safety.
4. Operate within -15°C ~45°C limits. Maintain 5%~65% relative humidity and allow at least 30cm clearance around vents for proper heat dissipation.
5. Calibrate the BMS before use, activate backup mode, and set charge/discharge thresholds. Verify communication protocol compatibility with your inverter for seamless integration.
FAQ
Q:What kind of certificates your products have acquired ?
A:Most of our solar products have acquired CE, and TUV certificates, which is able to satisfy most country's importing requirements.
Q:What are the voltage ranges for the custom cells offered by VP Batteries ?
A:VP Batteries offers custom cells in three main voltage ranges: Low Voltage (<12V): Suitable for specialized low-power devices. Medium Voltage(12 - 36V): Ideal for consumer electronics and small appliances. High Voltage (>36V): Designed for electric vehicles and large energy storage system
Q: How long does it take to ship after an order is completed?
A: The shipping time depends on the scale of the order and specific requirements. We provide an estimated shipping time after the order is confirmed.
Q: Can you handle large volume orders?
A: Absolutely. At Guangzhou Victory Technology Co., Ltd., we've got a staggering production capacity of billion batteries annually. No matter how large the volume of your order, we're prepared to deliver.
Q:How do we control the quality?
A:We will make samples before mass production and test them. After sample approved, we will begin mass production. Doing 100% inspection during production and then do random inspection before.
